High-Performance Inverter for HVAC Applications
Description
FRENIC-HVAC is Fuji Electric's energy-saving inverter optimized for HVAC systems. It provides intelligent fan and pump control, real-time feedback, and smart environmental response features. The inverter is ideal for air conditioning, ventilation, and water management in commercial buildings.
Features
- Slim body design with IP21/IP55 options
- Energy-saving functions including wet-bulb temperature presumption
- Built-in 4PID control and fire mode operation
- Linearization function and temperature differential control
- Filter clogging prevention and anti-jam protection
- Multi-language LCD keypad with real-time clock
- Built-in EMC filter and DCR up to 90kW
- Supports BACnet, Modbus RTU, CC-Link, and other fieldbus systems
Specifications
Power Range: 0.75 to 710kW
Enclosure: IP21/IP55 (up to 90kW), IP00 (110kW+)
Control Methods: V/f, Dynamic Torque Vector
Efficiency: Up to 98%
Certifications: UL508C, IEC/EN 61800-5-1
Cooling: Fan cooled
Overload: 110% for 1 minute (IEC 61800-2)
Interfaces: USB, RS-485, multi-language LCD
Optional Comms: BACnet, LonWorks, CANopen, CC-Link, Modbus, Ethernet
