Inverter

Compact High-Performance Inverter

Description

The FRENIC-Mini by Fuji Electric is a compact, high-performance inverter designed for general-purpose applications. It supports a wide range of power classes and offers easy operation, network compatibility, and global standards compliance. The inverter is ideal for fans, pumps, conveyors, and compact machinery.

Features

- High performance in a compact body
- Multipurpose and versatile for various applications
- Easy operation and maintenance
- Energy-saving functions for reduced operating costs
- Network compatibility with RS-485, Modbus
- Global compatibility with international standards
- Built-in braking transistor and EMC filter (select models)
- Wide voltage and power support across single-phase and three-phase series

Specifications

Model

FRENIC-Mini

Technical Specs

Voltage classes: Single-phase 100V/200V, Three-phase 200V/400V
Power range: 0.1kW to 15kW
Control methods: V/f control, dynamic torque vector control
Overload capacity: 150% for 1 min, 200% for 0.5 sec
Cooling: Natural or fan cooling based on model
Protection: IP20, UL Open Type
Certifications: UL508C, EN61800-5-1
Frequency range: 0.1Hz to 400Hz
Braking: Built-in DC injection braking, braking transistor (std.)
Interfaces: RS-485 (standard), keypad (option), analog and digital I/O

Frenic mini

Interested in this product?

Contact our sales team for pricing, availability, and technical support.

Looking for a specific model or accessory? This series includes additional variants, sizes, and accessories that aren't all listed here. As an authorized Fuji Electric distributor, we can supply the full range — just let our sales team know what you need.
