Energy & Electrical Measurements
T201 Series Current Transducers
Description
Comprehensive family of AC current transducers providing isolated analog outputs (4-20 mA or 0-10 V) from current measurements. Variants support 1/5 A TA input, direct insertion up to 600 A and Rogowski coil adapters. DIN-rail mounted with high accuracy and fast response, suitable for retrofitting and integration with controllers and indicators. See the PDF for the full range.
Features
Analog current-to-signal conversion, 4-20 mA / 0-10 V outputs, TA or direct insertion up to 600 A, Rogowski compatible, DIN-rail mount, High accuracy, Fast response
Specifications
Model
T201 Series
Technical Specs
Primary current: 1/5 A TA or 10–600 A direct; Output: 4-20 mA, 0-10 V or configurable; Accuracy: 0.5–1%; Isolation: 2 kVac; Operating temperature: -20 to +70 °C; Power supply: 24 Vdc
Interested in this product?
Contact our sales team for pricing, availability, and technical support.
Looking for a specific model or accessory?
This series includes additional variants, sizes, and accessories that aren't all listed here.
As an authorized Seneca distributor, we can supply the full range — just let our sales team know what you need.
