FUJI FRENIC-MEGA G2 INVERTER
Description
A high-performance, multifunctional inverter that offers outstanding control, versatility, and reliability for demanding industrial applications.
Features
- Supports vector control, sensorless vector control, dynamic torque vector control, and V/f control
- High-speed responsiveness with up to 599 Hz output
- Advanced torque ripple suppression for consistent quality
- Built-in PID control and customizable logic functions
- Predictive and preventive maintenance capabilities
- Compatible with a wide range of motors including synchronous and induction types
- Communication support for Modbus-RTU, CC-Link, Ethernet, and more
- Environmentally resistant and compliant with global standards (CE, UL, RoHS)
Specifications
Input voltage: 3-phase 200-240V / 380-480V depending on model
Rated power range: 0.4 kW to 800 kW (varies by model)
Control methods: Vector, sensorless vector, V/f, dynamic torque control
Protection: Built-in braking transistor (up to 75 kW), life expectancy monitoring, safety functions (STO)
Connectivity: RS-485, RJ-45, option cards for industrial networks
Temperature range: -10°C to +55°C
Enclosure types: IP00, IP20, IP55 (varies by version)
Interested in this product?
Contact our sales team for pricing, availability, and technical support.
