FUJI FRENIC-ACE E3 INVERTER
Description
The FRENIC-Ace E3 is a high-performance standard-type inverter designed for superior motor control, extensive versatility, and robust industrial adaptability.
Features
- High basic performance with support for various motor types
- Maximum frequency output of 599 Hz
- Supports V/f, vector, and sensorless vector control
- Side-by-side compact installation with space-saving design
- Predictive and preventive maintenance functions
- Built-in safety functions (STO) compliant with global standards
- Easy parameter migration and keypad operation
- Advanced torque vector control and positioning capabilities
- Compatible with Modbus RTU, BACnet MS/TP, and optional Ethernet protocols
- Long-life components with 10-year design expectancy (excluding finless type)
Specifications
Supported power supply: 3-phase 200V/400V and 1-phase 200V
Control modes: V/f, sensorless vector, vector control
Frequency range: Up to 599 Hz
Safety compliance: SIL3 (STO), CE, UL, RoHS, UKCA
Communication: RS-485, Modbus RTU, BACnet MS/TP; options for EtherNet/IP, CC-Link, PROFIBUS-DP
Environmental resistance: Operation up to 55°C, enhanced PCB coating (IEC60721-3-3: 3C2)
