FUJI PXF DIGITAL TEMPERATURE CONTROLLER
Description
The PXF Series offers high-speed, high-accuracy temperature control with universal input support and advanced features including auto-tuning, multi-zone control, and RS-485 communication, ideal for precise and reliable thermal regulation in industrial settings.
Features
- 50 ms high-speed sampling and ±0.2% accuracy
- Universal input: thermocouple, RTD, voltage, current
- PID, fuzzy, 2-degrees-of-freedom PID, and self-tuning control
- RS-485 communication with multi-drop master function
- Compact design with 58 mm depth for easy installation
- Up to 64-step ramp/soak program control
- Energy-saving features including watt-hour metering and soft start
- Alarm output (up to 5), heater burnout detection, operating days alarm
- Multiple sizes: PXF4 (48x48 mm), PXF5 (48x96 mm), PXF9 (96x96 mm)
Specifications
Control modes: ON/OFF, PID, fuzzy, self-tuning, PID2, 2-degrees-of-freedom PID
Sampling rate: 50 ms
Output types: Relay contact, SSR drive, current, voltage, motorized valve
Display: 4-digit, backlit LCD with status indicators
Communication: RS-485 (Modbus-RTU), PC loader interface
Program capacity: Up to 64 steps, 8 patterns
Power supply: 100–240V AC or 24V AC/DC
Certifications: CE, UL, RoHS (implied by design standards)
