Tachometers
Digital Tachometer TM-7000 (Basic Laser Type)
Description
The TM-7000 is a basic laser-type digital tachometer for non-contact rotational speed measurement. Uses a highly visible laser for easy measurement adjustment with a measuring distance of up to 1m from a reflective target. Contact measurement is possible with the optional TM-7013 contact adaptor.
Features
- Non-contact laser measurement (Class 2 laser)
- Highly visible laser for easy measurement adjustment
- Measuring distance up to 1m from reflective target
- 6.0 - 99999.9 rev/min measuring range
- 0.1 rev/min resolution
- Auto power-off after 3 minutes
- Contact measurement possible with TM-7013 adaptor (optional)
- CE and RoHS compliant
Specifications
Model
TM-7000
Measuring Range (Non Contact)
6.0 - 99999.9 r/min
Measuring Range (with TM 7013 Contact Adaptor)
6.0 - 15000.0 r/min
Resolution
0.1 r/min
Accuracy
±0.01% ±1 digit
Sampling Time
1.0-10.0 sec (non-contact) / 1.0-2.0 sec (with contact adaptor)
Display
6 digits, 7 segment LCD
Optical System
Laser Class 2, 650nm CW, Max 1mW, Operating range 50-1000mm ±40°
Power Supply
4 x AAA alkaline battery
Battery Life
Approx. 30 hours
Auto Power Off
After 3 minutes from last measurement or key operation
Operating Temperature
5-40°C (operating) / -10 to +60°C (storage, non-freezing)
Operating Humidity
35-85%RH (non-condensing)
Dimensions
125(H) x 58(W) x 27.4(D) mm
Weight
140g (battery included)
Included Accessories
Reflective tape x10, AAA alkaline battery x4, Instruction manual
